Managing queues

A queue is a named scheduling lane. It does two jobs at once: it routes work to a cluster pool (and, optionally, specific clusters within it), and it governs that work with concurrency, depth, priority, and fairness limits.

This page covers creating and managing queues administratively, from either the CLI or Python. For how workflow authors target a queue from task code, see Queues in Configure tasks.

How a queue routes

A queue lives inside one cluster pool and routes work to one or more clusters within that pool. By default (the * selector) it spreads across the pool’s healthy, active clusters; you can also pin it to specific clusters. It can never reach a cluster in another pool: pools are isolation boundaries.

            flowchart TD
    R(["Runs & actions"])

    subgraph Pdef["Cluster pool: default"]
        direction TB
        QD["Queue: default<br/>selector: *"]
        CA["Cluster A"]
        CB["Cluster B"]
        QD --> CA
        QD --> CB
    end

    subgraph Pprod["Cluster pool: prod"]
        direction TB
        QP["Queue: prod-queue<br/>selector: *"]
        QG["Queue: gpu-queue<br/>pinned: Cluster C"]
        CC["Cluster C"]
        CD["Cluster D"]
        QP --> CC
        QP --> CD
        QG --> CC
    end

    R --> QD
    R --> QP
    R --> QG


Users submit to a queue, never to a pool or a cluster directly. Each queue sits inside exactly one pool:

• default spreads across the eligible clusters in the default pool.
• prod-queue spreads across the eligible clusters in the prod pool.
• gpu-queue lives in the same prod pool but is pinned to a single cluster.

Queues you get for free

You don’t have to create a queue to have one. Two exist without any action on your part:

• The org-wide default queue, in the default pool with the * selector. Anything that doesn’t explicitly target a queue goes here. (If the default queue is drained or deleted, untargeted submissions are rejected until it is active again — a restored queue comes back drained, so after an undelete it must also be reactivated.)
• A co-named queue for every cluster: registering a cluster creates a queue with the same name as the cluster, in that cluster’s pool, whose selector names that one cluster explicitly rather than using *. Register prod-us-east-1 and you get a prod-us-east-1 queue that routes only to prod-us-east-1 — so any cluster can be targeted by name immediately, without setting up a queue for it. See The co-named queue.

Both are ordinary queues: they show up in flyte get queue and take the same settings and updates as queues you create yourself — with one exception. A co-named queue’s cluster selector and pool are managed by its cluster and cannot be edited directly: the queue follows its cluster if the cluster is reassigned to another pool. It also follows the cluster through drain, activate, and delete transitions, and it cannot be activated on its own while its cluster is draining or drained (see How the co-named queue follows its cluster). The cluster and queue finish their transitions separately, so they may reach their final states at slightly different times. Its other settings (concurrency, depth, priority, fairness) stay editable like any queue’s. Listings make the distinction visible: cluster-managed queues are flagged in the flyte get queue table (cluster_managed, exposed as Queue.cluster_managed in Python), and flyte update queue --edit says so at the top of the edit buffer.

The selector (which clusters within the pool) is mutable and can be changed at any time. The pool a queue lives in can only change once the queue is fully drained: a pool move on an active or draining queue is rejected, because moving a queue that still holds work would cross an isolation boundary. See Move work to another pool.

Create a queue

run_concurrency and action_concurrency are required; everything else has a sensible default. With no cluster selector, a queue spreads work across all healthy clusters in its pool. The name default is reserved, and a queue cannot share a name with a cluster — every cluster already owns its co-named queue — or with a soft-deleted queue, whose name stays reserved until it is undeleted.

flyte create queue my-queue \
  --run-concurrency 100 \
  --action-concurrency 1000

flyte create queue gpu-queue \
  --cluster-pool prod \
  --cluster prod-us-east-1 \
  --run-concurrency 50 \
  --action-concurrency 500 \
  --depth 5000 \
  --priority max \
  --fairness round_robin

from flyteplugins.union.remote import Queue

queue = Queue.create(
    "my-queue",
    run_concurrency=100,
    action_concurrency=1000,
)

print(queue.to_dict())

queue = Queue.create(
    "gpu-queue",
    cluster_pool="prod",
    clusters=["prod-us-east-1"],
    run_concurrency=50,
    action_concurrency=500,
    depth=5000,
    priority="max",
    fairness="round_robin",
)

What each setting controls

• cluster_pool / --cluster-pool: the pool this queue lives in. A queue can only route to clusters in its own pool. Omit to bind the queue to the default pool.
• clusters / --cluster: pin the queue to one or more clusters in the pool. Omit to use all clusters in the pool. In the API, ["*"] means all active, healthy clusters in the pool (see Wildcard routing), and * must be the only entry if used.
• run_concurrency / --run-concurrency: maximum number of runs active on the queue at once. Children of an active run aren’t counted; use this to stop a job from overlapping with a previous invocation of itself. 0 means no limit.
• action_concurrency / --action-concurrency: maximum number of actions (tasks) running at once. A cap of 1 serializes the queue; higher values bound the burst rate. 0 means no limit.
• depth / --depth: total in-flight plus waiting items the queue will hold (default 10000). 0 means no limit.
• priority / --priority: min, medium (default), or max. Among queues contending for the same pool’s capacity, higher-priority work is scheduled first. Under the hood these map to enum values 1, 50, and 100; use max for a priority higher than 50. Priority controls ordering, not preemption.
• fairness / --fairness: round_robin (default) or shuffle_interleave. This controls how actions from different projects sharing the queue are interleaved.

Inspect queues

# List all queues
flyte get queue

# List live queues in one state: active, draining, drained, or deleting
flyte get queue --state draining

# Inspect one queue's settings and status
flyte get queue gpu-queue

# Stream live metrics — runs in-flight, actions in-flight, queue depth
flyte get queue gpu-queue --watch

# List soft-deleted queues (hidden from the plain listing)
flyte get queue --deleted

from flyteplugins.union.remote import Queue

for queue in Queue.listall(limit=100):
    print(queue.name, queue.status, queue.priority, queue.cluster_pool, queue.clusters)

# Narrow the live listing to one lifecycle state: "active", "draining",
# "drained", or "deleting"
for queue in Queue.listall(state="draining"):
    print(queue.name)

# Deleted queues are hidden from the listing unless you ask for them
for queue in Queue.listall(deleted=True):
    print(queue.name)

queue = Queue.get("gpu-queue")
print(queue.to_dict())

metrics = Queue.details("gpu-queue")
print(metrics)

for metrics in Queue.watch("gpu-queue"):
    print(metrics)

Change a queue’s settings

You can update limits, priority, fairness, or cluster pinning. The update API replaces the full queue spec; the Python wrapper handles this by reading the current queue first, changing only the fields you pass, and writing the complete spec back.

flyte update queue gpu-queue --edit

from flyteplugins.union.remote import Queue

Queue.update(
    "gpu-queue",
    run_concurrency=75,
    action_concurrency=750,
    priority="max",
    clusters=["prod-us-east-1"],
)

Changing the cluster selector within the same pool (which clusters the queue pins to) takes effect immediately because every cluster in the pool shares the same data plane.

Changing the queue’s pool (cluster_pool in the YAML or Python) is allowed only when the queue is drained, the destination pool exists, and every cluster in the queue’s selector is a member of the destination pool — see Move work to another pool. A cluster’s co-named queue rejects selector and pool changes entirely: those are managed by its cluster. A soft-deleted queue cannot be updated at all; undelete it first.

Queue lifecycle

A queue is in one of five lifecycle states. The drain, activate, delete, and undelete transitions are requested by you; the moves into drained and deleted are made by the system once it confirms the queue holds nothing.

            stateDiagram-v2
    direction LR
    [*] --> active: create
    active --> deleting: cluster deleted (co-named queue only)
    draining --> deleting: delete
    deleting --> deleted: cleanup done (system)
    active --> draining: drain
    draining --> active: activate
    draining --> drained: no work left (system)
    drained --> active: activate
    drained --> deleted: delete
    deleted --> drained: undelete


• active: accepting new submissions.
• draining: no new submissions; in-flight work runs to completion. The system moves the queue to drained once it confirms the queue holds no run or cleanup work.
• drained: confirmed empty. The only state from which a delete completes in one step, the only state in which the queue can change pools, and the state a restored queue comes back in.
• deleting: deletion requested while the queue may still hold work. The system aborts the queue’s remaining run work, waits for cleanup work, and then moves the queue to deleted. The queue stays listed meanwhile.
• deleted: soft-deleted. Hidden from listings and never scheduled on; the name stays reserved and flyte get queue <name> still returns it.

What each operation does from each state:

A cluster’s co-named queue is the one exception in the --activate column: while its cluster is draining or drained, the queue cannot be activated on its own. Activating the cluster activates it.

Three rules follow from the table:

• Deleting a queue is a safe archive operation. A queue must always be drained before it can be deleted: there is no path from active into deletion that you can request on a queue, so deleting a queue that is accepting work always takes two calls, a drain and then a delete. A single misdirected command can never take a serving queue away, and the delete itself only archives the record. The one indirect path is deleting a cluster, which takes the cluster’s co-named queue into deletion whatever state it is in; that path is only as safe as the cluster delete that triggers it.
• Deletion cannot be canceled: a deleting queue can only become deleted, and only then can it be undeleted.
• drained and deleted are never requested directly; the system transitions into them once it has confirmed the queue holds nothing.

Draining a cluster drains its co-named queue and activating the cluster activates it; see How the co-named queue follows its cluster.

Drain and reactivate a queue

Draining takes a queue out of rotation without losing in-flight work: the queue stops admitting new submissions, work already in flight runs to completion, and once nothing is left the queue settles into the drained state. Use it before maintenance, deletion, or as part of moving work to another pool.

flyte update queue gpu-queue --drain      # stop new submissions; let in-flight work finish
flyte update queue gpu-queue --activate   # put the queue back in rotation

from flyteplugins.union.remote import Queue

Queue.drain("gpu-queue")     # stop new submissions; let in-flight work finish
Queue.activate("gpu-queue")  # put the queue back in rotation

To see where things stand across the organization, filter listings by state: flyte get queue --state draining shows the queues still finishing in-flight work, --state drained the ones that are done, and --state deleting the ones being removed.

An active queue must start draining before it can be deleted, but you do not have to wait for drained: deleting a draining queue begins its cleanup immediately. A pool move does require the queue to be fully drained. Deleting a cluster automatically takes its co-named queue into deletion, whatever state that queue is in.

Any queue can be drained, including the default queue and a queue configured as the default run queue (run.default_queue) in your organization’s settings at any scope — draining is how you stop scheduling on it, and the prerequisite for deleting it. A draining or drained queue still resolves as the default: runs that land on it are rejected with an error saying the queue is not accepting work. Only deleting a queue referenced in settings is refused.

Delete a queue

A queue must be draining or drained before it is deleted: an active queue is rejected, so start draining it first. This is what makes deleting a queue a safe archive operation, in contrast to deleting a cluster, which can interrupt work. Once the queue is draining you can choose whether to wait:

• Deleting a draining queue moves it to deleting. Queued and running actions on it are failed rather than finished, as a final attempt that is not retried; cleanup work is left to run. The system moves the queue to deleted once nothing remains on it.
• Deleting a drained queue moves it directly to deleted, because the system has already confirmed that no work or cleanup remains.

Deletion cannot be canceled. A deleting queue rejects every further request: it cannot be drained, activated, deleted again, or undeleted. Wait until it becomes deleted before undeleting it.

A queue referenced as the default run queue (run.default_queue) in settings at any scope can be drained but not deleted: update or unset those settings first. A cluster’s co-named queue can be deleted on its own while the cluster lives. Deleting the cluster also deletes its co-named queue and is the only operation that can take that queue directly from active to deleting; that cascade does not apply the run.default_queue check, so a co-named queue used as a default run queue goes away with its cluster.

The default queue is no exception: drain it, then delete it, like any other queue — deleting it is also how the default pool is emptied of live queues so that the pool itself can be deleted. While the default queue is deleted, submissions that name no queue and have no run.default_queue setting to fall back on are rejected at creation. Nothing re-creates it implicitly; flyte undelete queue default brings it back.

flyte delete queue gpu-queue
flyte delete queue gpu-queue --yes   # skip the confirmation prompt

# List deleted queues, restore one
flyte get queue --deleted
flyte undelete queue gpu-queue

from flyteplugins.union.remote import Queue

queue = Queue.delete("gpu-queue")
print(queue.status)           # deleting or deleted
Queue.undelete("gpu-queue")   # restore a deleted queue

A deleting queue remains visible in normal listings while cleanup runs, and it can still be inspected or watched. Once deleted, it is soft-deleted: it disappears from normal listings and is no longer scheduled on, but its name stays reserved. Fetching it by name still works — flyte get queue <name> and Queue.get return the queue with its deletion time. Use flyte get queue --deleted to list deleted queues.

Restore it with flyte undelete queue <name>. The queue’s pool and pinned clusters must still be live. A cluster’s co-named queue undeletes like any other queue while its cluster is live; while the cluster is deleted, the undelete is refused and undeleting the cluster brings the queue back with it. The restored queue comes back drained; reactivate it to resume routing.

Move work to another pool

Moving work to a different pool crosses an isolation boundary. In-flight runs have already landed their data, containers, code, and secrets in the old pool’s data plane, and a different pool’s clusters cannot read them. So work in flight never moves: the migration is always drain-first, in one of two shapes.

Move the queue itself. A queue can change pools once it holds no work:

1. Drain the queue and wait for it to reach the drained state.
2. Update the queue’s pool — flyte update queue <name> --edit and change cluster_pool in the YAML, or Queue.update(name, cluster_pool=...) — and set its cluster selector to clusters that are members of the destination pool (or *).
3. Reactivate the queue.

Anything targeting the queue by name follows it to the new pool. New submissions made while it is drained are rejected, so coordinate the window with the queue’s users.

Replace the queue. Alternatively, keep the old queue’s pool binding and shift traffic over:

1. Create a new queue in the destination pool.
2. Update workflows, launch plans, triggers, or run overrides to target the new queue.
3. Drain the old queue to shut out straggler submissions and let in-flight work finish.
4. Delete the drained queue, or leave it idle — an idle queue costs nothing.

See also

• Queues in Configure tasks: routing work to a queue from task code, triggers, and per-run context.
• Cluster pools and Clusters: the routing targets a queue points at.
